DTC Lookup

Possible Causes

• 1. Body control module (BCM) configuration is not completed. (See CONFIGURATION .) 2. Improper assembly of humidity sensor/solar radiation sensor/auto light sensor/rain sensor (Part with different part number is installed.) (Refer to [RAIN SENSOR REMOVAL/INSTALLATION] in workshop manual.) 3. Humidit

BCM

B10AD:09 [BCM]

SM3339437

---

id990210107600

System malfunction location	Humidity sensor/solar radiation sensor/auto light sensor/rain sensor malfunction
Detection condition	• The body control module (BCM) detects the humidity sensor/solar radiation sensor/auto light sensor/rain sensor malfunction.
Fail-safe	• Not applicable
Possible cause	1. Malfunction in wiring harness (including connector/terminal) between humidity sensor/solar radiation sensor/auto light sensor/rain sensor and body control module (BCM) (See CIRCUIT INSPECTION.) (See CONNECTOR INSPECTION.) 2. Humidity sensor/solar radiation sensor/auto light sensor/rain sensor malfunction (Refer to [RAIN SENSOR INSPECTION] in workshop manual.) 3. Body control module (BCM) malfunction (Refer to [BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION] in workshop manual.)
Repeatability verification procedure	1. Clear the DTC recorded in the memory. (See CLEARING DTC.)
1	Body control module (BCM)
2	Humidity sensor/solar radiation sensor/auto light sensor/rain sensor
